Items | Specifications | MIT300 | MIT500 |
Eyepieces | WF10X -18mm | ●● | ●● |
WF10X -18 mm (Reticule 0.1mm) | ● | ● |
WF5X | ○○ | ○○ |
WF12.5X | ○○ | ○○ |
Infinity Plan Objective (no cover glass) | 5X/0.11 | W.D=12.10mm | ● | ● |
10X/0.25 | W.D= 4.75mm | ● | ● |
20X/0.4(S) | W.D= 2.14mm | ○ | ○ |
40X/0.65 (S) | W.D= 0.45mm | ○ | ○ |
100X/1.25(Oil)(S) | W.D= 0.12mm | ○ | ● |
Long Working Distance Infinity Plan Objective (no cover glass) | 20X/0.4 (S) | W.D= 8.35mm | ● | ● |
40X/0.65 (S) | W.D= 3.90mm | ● | ● |
50X/0.7 (S) | W.D= 1.95mm | ○ | ○ |
80X/0.80 (S) | W.D= 0.85mm | ○ | ○ |
Seidentopf Binocular Head | Inclined 30°,Rotatable 360°,
Interpupilary Distance: 50-75mm | ● | ● |
Seidentopf Trinocular Head | Inclined 30°,Rotatable 360°,
Interpupilary Distance: 50-75mm
Light Distribution: 0:100 | ○ | ○ |
Nosepiece | Quintuple | ● | ● |
Mechanical Stage For Reflection Illumination | Stage Size: 200X140mm,Travel: 78mmX55mm
Stage Fast Lowering Unit: Stage Up-Down moving range can be 50mm (Max.) | ● | |
Mechanical Stage For Transmission Illumination | Stage Size: 190X140mm,Travel: 78mmX55mm
Coaxial Coarse and Fine Focusing Knobs | | ● |
Stage Plate | Place The Sample on The Plate | ● | ● |
Clip | | | ● |
Glass Plate | | | ○ |
Stage Micrometer | 0.01mm | ○ | ○ |
Polarizing Unit | Polarizing /Analyzer Slide | ● | ● |
Condenser | Abbe N.A. 1.25(Iris Diaphragm) | | ● |
Illumination | 12V/50W Halogen Lamp (Reflection Illumination) | ● | ● |
6V/20W Halogen Lamp (Transmission Illumination) | ○ | ● |
6V/30W Halogen Lamp(Transmission Illumination) | ○ | ○ |
Field Diaphragm | | | ● |
Filter | Blue | ○ | ● |
Green | ○ | ○ |
Yellow | ○ | ○ |
C-mount | 1X | ○ | ○ |
0.57X （Focus Adjustable） | ○ | ○ |
